3-13
OPERATION
1. Increase the engine speed.
2. Fully lower the safety lock lever to
disengage the lock.
OPERATING THE MACHINE
Preparing for travel
1. Set the steering device facing forward and
to the front of the operator’s seat.
2. Fully raise the boom, fully lower the
second boom, and then set the arm
vertically to rollback the bucket.
3. Fully raise the blade/outriggers (if
equipped).
For machines equipped with outriggers,
secure them with turnbuckles.
4. Engage the slew lock.
5. Tilt the reflector.
Travel Posture
Moving forward and in reverse
3. Press the ram lock switch to the neutral
position to disengage the ram lock.
