7-5
SPECIFICATIONS
Unit: mm (inch)
Item 2-Piece boom
A Overall length 6030 (237.5)*/ 6085 (239.5)
B Overall width 2525 (99.4)
C Overall height 3985 (156.9)
D Slew radius 2065 (81.4)
E Clearance height under upperstructure 1245 (49.0)
F Wheel base 2565 (101)
G Tread 1945 (76.5)
H Overall length of undercarriage 4600 (181.1) *
J Overall height of base machine 3130 (123.1)
K Ground clearance of undercarriage 275 (10.8) *
L Front distance to axis of rotation 3860 (152.0)
M Rear distance to axis of rotation 2170 (85.4)
N Dozer blade width 2480 (97.6)
P Dozer blade height 600 (23.6)
Q Swing angle of axles 7.5°
R Minimum turning radius (Tire) 6380 (251.2)
S Minimum turning radius (Dozer blade) 7025 (276.5)
T Outside machine clearance radius 7295 (287.2)
U Width of pad outrigger retracted 2500 (98.4) *
V Width of pad outrigger extended 3555 (140.0) *
W Overall width of upperstructure 2460 (96.9)
*: With an outrigger
MACHINE DIMENSIONS
