7-7
SPECIFICATIONS
2-Piece boom
OPERATING RANGES
Unit: mm (inch)
Item 2570 mm (101.2 in) arm
A Maximum reach 8885 (349.8)
B Maximum reach at ground reference plane 8705 (342.8)
C Maximum digging depth 5555 (218.7)
D Maximum vertical digging depth 4965 (195.5)
E Reach at maximum vertical digging depth 4480 (176.4)
F Maximum height of cutting edge 10030 (394.8)
G Maximum dumping height 7580 (298.3)
H Minimum dumping height 3020 (118.8)
J Dozer blade maximum lifting 480 (18.9)
K Dozer blade maximum lowering 140 (5.6)
