Takeuchi TB225 User Manual

2-27
CONTROLS
a. When the selection bar is at ALARM,
press the (A) key to proceed to the alarm
setting screen (ALARM SET).
b. Press the (A) key in this screen to place
a checkmark in the box at the left of the
setting bar. Press the (A) key again to
remove the checkmark.
The alarm setting cannot be changed
only by placing or removing a
checkmark.
c. Press and hold the (A) key for at least
two seconds to complete the setting
and to return to the Setting Selection
screen.
Be sure to perform the above operation
when you wish to set the alarm.
A clock symbol is displayed on the
Home screen.
d. Press the (B) key to move the selection
bar.
e. Press and hold the (B) key for at least
three seconds to enter the alarm time
setting mode.
f. Press the (C) key to cancel editing and
to return to the Setting Selection screen.
Checked ............On
Unchecked ........Off
INSTRUMENT CLUSTER
• Alarm time setting mode
Sets the time for alarm.
a. Select the item to be set in the alarm
setting screen (ALARM SET).
b. Press and hold the (B) key for at least
three seconds to enter the alarm time
setting mode.
c. Press the (A) key in this screen to move
the selection bar and to flash the figures
on the bar.
Setting range: hours, 1 to 24; minutes,
00 to 59
d. Press the (B) key to increase the number
value selected.
Press and hold the (B) key to rapidly
increase the number value selected.
e. Press and hold the (A) key for at least
two seconds to complete the setting
and to return to the Setting Selection
screen.
f. Press the (C) key to cancel editing and
to return to the Setting Selection screen.
• Alarm setting (ALARM)
Five patterns of alarm setting are
available.
Alarm function can be set to on or off
within the five patterns.

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
