MAINTENANCE
Service Data
Tools
J1G017
1
2
3
4
6
7
8
9
10
1
1 12
13
14
15 16 17
18
19
20
21
23
22
13 Hammer 16903-00330 3/4
14 Hex. wrench
16906-00400 4mm
15 Hex. wrench
16906-00500 5mm
16 Hex. wrench
16906-00600 6mm
17 Hex. wrench
16906-00800 8mm
18 Hex. wrench
16906-01000 10mm
19 Hex. wrench
16906-01400 14mm
20 Grease gun
16910-60610 600cc
21 Tool case
16914-00001
22 Drain connector 15545-12601 for EU
23 Case
16919-00001
No. Part name
Part No.
Remarks Part nameNo. Part No. Remarks
1 Spanner 19100-47081 10-12
2 Spanner
19100-47082 14-17
3 Screwdriver
19100-06112 (+) (–)
4 Filter wrench
19100-65081
6 Monkey wrench 16904-00250 250mm
7 Spanner
16900-01922 19-22
8 Spanner
16900-02427 24-27
9 Spanner
16901-00013 13
10 Spanner
16901-00041 41
11 Spanner
16909-00026 26
12 Pliers
16905-00200 200mm
