Rugged Mini E1 | User’s Manual
SATA1: SATA with Power Connector
Pin Definition Pin Definition
1 GND 12 GND
2 SATA_TXP1 13 GND
3 SATA_TXN1 14 +5V
4 GND 15 +5V
5 SATA_RXN1 16 +5V
6 SATA_RXP1 17 GND
7 GND 18 GND
8 +3.3V 19 GND
9 +3.3V 20 +12V
10 +3.3V 21 +12V
11 GND 22 +12V
Chapter 2: Switches and Connectors
24
