TASCAM DP-006
15 – Specifications
Media and file systems
Recording media
SD card (512 MB–2 GB)
SDHC card (4 GB–32 GB)
File system
MTR partition: TASCAM original
FAT partition: FAT32
Inputs and outputs
Analog audio input and output
INPUT A jack
Connector: 6.3mm (1/4”) TS standard jack
Input impedance:
10 kΩ or greater (when INPUT A switch set to MIC/LINE)
1 MΩ (when INPUT A switch set to GUITAR)
Standard input level: −10dBV
Maximum input level: +6dBV
Headroom: 16dB
INPUT B jack
Connector: 6.3mm (1/4”) TS standard jack
Input impedance: 10kΩ or greater
Standard input level: −10dBV
Maximum input level: +6dBV
Headroom: 16dB
Built-in microphones
Omnidirectional x2
/LINE OUT jack
Connector: 3.5mm (1/8”) stereo mini jack
• When line is connected
Standard output level: −16dBV
Maximum output level: 0dBV
• When headphone is connected
Standard output level: 15mW+15mW (THD+N 0.1% or less, 32Ω load)
Data input and output
USB jack
Connector: USB Mini-B 4-pin
Format: USB 2.0 HIGH SPEED mass storage class
Audio performance
Frequency response
INPUT(MIC/LINE) w LINE OUT: 20Hz–20kHz, +1dB/−3dB
Distortion
INPUT(LINE) w LINE OUT: Less than 0.05%
S/N ratio
INPUT(MIC/LINE) w LINE OUT: More than 81dB
