Installing and Setting up the Machine > Part Names (Machine Exterior)

24 Paper Width Adjusting Tab

25 Paper Width Guide

26 Paper Length Guide

27 Right Cover 1 Lever

28 Right Cover 1

29 Paper Width Guide

30 Multipurpose Tray

31 Support Tray Section of the Multipurpose Tray

27 282624
