K580M
CONTROL PANEL FOR ONE 230V AC MOTOR
ATTENTION:
- do not use single cables (with one single wire), ex. telephone cables, in order to avoid
breakdowns of the line and false contacts;
- do not re-use old pre-existing cables.
TESTING
When you have completed the connection:
off only when the controls to which they are associated are operated.
be illuminated steadily.
TECHNICAL CHARACTERISTICS
Power input to board
Nominal power 400 W
Input voltage of motor circuits
IP 44
TERMINAL BOARD CONNECTIONS
Terminals Function Description
1 - 2 - 3
POWER
SUPPLY
4 - 5
FLASHING
LIGHT
6 - 9 OPEN/CLOSE
7 - 9 PEDESTRIAN
N.B. by factory setting the automation will open 120 cm.
8 - 9 STOP
10 - 11
SENSITIVE
EDGE
NOTE: if a resistive sensitive edge is connected, set dip-
switch no. 12 to ON;
switch no. 12 to OFF;
ENGLISH
To Next Page
