5
Models 104 & 220
Introduction
090811
220 Specifications
Freezing Cylinder
One, 20 quart (18.9 liter)
Mix Hopper
One, 10 quart (9.5 liter)
Beater Motor
One, 1.5 HP
Refrigeration Unit
One, approximately 15,000 BTU/hr. R404A
(BTU’ s may vary depending on compressor used.)
Electrical
Electrical
One dedicated connection
Maximum
Fuse Size
Minimum
Circuit Ampacity
208-230/60/1 Air 40 30
208-230/60/1 Water 40 27
208--230/60/3 Air 30 22
208--230/60/3 Water 30 19
220--240/50/1 Air 30 25
220--240/380 --415/
50/3 Air
15 12
This unit is also available with other electrical
characteristics. (For exact electrical information,
always refer to the data label of the unit.)
Air Cooled
Clearance: 3” (76 mm) around all sides. Install the
deflector provided to prevent recirculation of warm air.
Water Cooled
W ater inlet and drain connections under side of base
3/8” FPT.
Dimensions
Width: 18--7/16” (468 mm)
Depth: 40--1/2” (1029 mm)
Height:56--1/2” (1435 mm)
Floor Clearance: 4--1/4” (108 mm), mounted on
standard casters.
Approximate Weights
Net: 500 lbs. (226.8 kgs.)
Crated:590 lbs. (267.6 kgs.)
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF and other
food service regulatory agencies.
