Models 150, 152, 162, 168 Operator Parts Identification
Section 4 Operator Parts Identification
Model 150
Figure 1
Item Description Part No.
1 Cover A.- Hopper X48690
2 Tube- Feed- .166 Hole 035819
3 Float A.- Mix Level X39690
4 Panel- Back Top 050429
5 Panel- Upper Side Left 030783- SS
6 Pan - Drip 11- 5/8 Long 027503
7 Panel- Back Bottom 050430
8 Panel- Lower Side 030792- SS
9 Panel- Insert 025533- SS
10 Panel A.- Lower Front X25518
11 Tray- Drip 10- 7/8 x 4 - 7/16 025062
12 Shield - Splash 11- 1/4 x 4 - 13/16 025063
Item Description Part No.
13 Decal- Decorative- Taylor 047667
14 Panel- Upper Side Right 030784- SS
15 Light - Amber- Round Mix Low 039707
16 Caster- 3” Swivel 012227
17 Panel A.- Front X25036
18 Trim- Top Back Panel 025536
19 Trim- Middle Back Panel 025537
20 Trim- Side & Front 025528
21 Plate - Decorative 041034- SS
22 Holder- Drip Tray 035866
23 Caster- 3” Rigid 012226
