Taylor 152 User Manual

10
Models 150, 152, 162, 168Operator Parts Identification
Model 168
Figure 4
Item Description Part No.
1 Cover A.- Hopper X37963 - SER
2 Tube- Feed- .166 Hole SS 030797
3 Float A.- Mix Level X39690
4 Panel - Top Back 030790- SS
5 Panel - Upper Side Left 030783- SS
6 Pan- Drip 17 - 1/4” Long 027504
7 Panel A.- Front X30711
8 Light- Amber- Round Mix Low 039707
9 Decal- Decorative - Taylor 047666
10 Shield- Splash 17 - 5/8 Long 030789
11 Tray - Drip 16 - 7/8 Long 030565
Item Description Part No.
12 Panel- Upper Side Right 030784- SS
13 Insert- Front Panel 030773- SS
14 Panel A. - Lower Front X30747
15 Panel- Bottom Back 055833
16 Caster- 3” Rigid (Rear) 012226
17 Caster- 3” Swivel (Front) 012227
18 Panel- Lower Side- Right/Left 030792- SS
19 Trim- Top Back Panel 030775
20 Trim- Middle Back Panel 030795
21 Plate- Decorative 039723- SS
22 Holder- Drip Tray 035866

Taylor 152 Specifications

General

Brand	Taylor
Model	152
Category	Freezer
Language	English
