USER INTERFACE
5-3
Model C722
User Interface
5
Standby Symbol
During long no sale periods, the machine can be placed
in Standby mode. This maintains product temperatures
below 40°F (4.4°C) in both the hopper and the freezing
cylinder and helps prevent overbeating and product
breakdown.
To activate Standby mode, press the Standby symbol
key or enter the access code for the Manager’s
Menu and select the Standby mode option (see pages
5-5 and 5-7). The Standby symbol will illuminate,
indicating the Standby feature has been activated.
Note: To resume normal operation, press the Auto
symbol
key. When the machine cycles off, the
product in the freezing cylinder will be at serving
viscosity.
Wash Symbol
The Wash symbol will illuminate when pressed. This
indicates beater motor operation. The Standby or Auto
modes must be canceled first to activate the Wash mode.
Auto Symbol
The Auto symbol will illuminate when pressed. This
indicates that the refrigeration system has been
activated. In the Auto mode, the Wash or Standby
functions are automatically canceled.
Note: An indicating light will illuminate and a tone will
sound whenever a mode of operation has been selected.
To cancel any function, press the key again. The light and
the mode of operation will shut off.
Topping Heater Symbols
The Topping Heater symbols are not functional on the
Model C722.
Reset Mechanism
The reset buttons are located in the left side panel of the
machine. They protect the beater motors from
overloading. Should an overload occur, the reset
mechanism will trip. To properly reset the freezer, place
the power switch in the OFF position. Press the reset
button firmly. Turn the power switch to the ON position.
Press the Wash symbol
and observe the freezer's
performance.
CAUTION! DO NOT use metal objects to press
the reset button. Failure to follow this instruction may
result in electrocution.
If the beater motor is turning properly, press the Wash
symbol
to cancel the cycle. Press the Auto symbol
to resume normal operation. If the freezer shuts
down again, contact your authorized service technician.
Adjustable Draw Handle
This machine features an adjustable draw handle to
provide the best portion control, giving a better,
consistent quality to your product and controlling costs.
The draw handle should be adjusted to provide a flow
rate of 5 oz. to 7-1/2 oz. (148 ml to 222 ml) of product by
weight per 10 seconds. To increase the flow rate, tighten
the screw. To decrease the flow rate, loosen the screw.
(See Figure 5-2.)
Figure 5-2
