Taylor C723 Service Manual

19
Model C723
Controls, Systems and Operations
After the correct month, day, and year have been
entered, press the SEL key to advance to the
DAYLIGHT SAVING TIME (DST) screen.
(See Figure 18.)
DAYLIGHT SAVING TIME
ENABLED
> Enable
Disable
Figure 18
Pressing the UP or DOWN arrow keys will move the
arrow to “Enable” or “Disable”. Pressing the SEL key
with the arrow next to “Disable” selects that option
and returns to the Manager's Menu. Pressing the
SEL key with the arrow next to “Enable” selects that
option and displays the second screen.
(See Figure 19.)
MAR Second Sunday
NOV First Sunday
Change
> Exit
Figure 19
If the correct Sunday for the time change is not
displayed, then “Change” should be selected.
Pressing the SEL key with the arrow next to
“Change” displays the third screen. Press the UP or
DOWN arrow key to move the arrow to the
appropriate month for the start of DST.
(See Figure 20.)
DST START MONTH
> MAR
APR
MAY
Figure 20
Pressing the SEL key with the arrow next to the
appropriate month will display the following screen.
(See Figure 21.)
DST START WEEK
> Second Sunday
Third Sunday
Fourth Sunday
Figure 21
Pressing the UP or DOWN arrow key will move the
arrow to the appropriate week for the start of DST.
Pressing the SEL key with the arrow next to the
appropriate week will display the following screen.
Press the UP or DOWN arrow key to move the
arrow to the appropriate month for the end of DST.
(See Figure 22.)
DST END MONTH
> NOV
DEC
Figure 22
Pressing the SEL key with the arrow next to the
appropriate month will display the following screen.
Press the UP or DOWN arrow key to move the
arrow to the appropriate week for the end of DST.
(See Figure 23.)
DST END WEEK
> First Sunday
Second Sunday
Third Sunday
Figure 23
Pressing the SEL key with the arrow next to the
appropriate week will select that setting and return to
the Manager's Menu.
The AUTO START TIME option allows the manager
to set the time of day at which the machine
automatically enters the AUTO mode from the
STANDBY mode. The machine must be in the
STANDBY mode in order to AUTO START at the
programmable time. The AUTO START TIME can
also be disabled and require starting the AUTO
mode manually. (See Figure 24.)
AUTO START TIME
DISABLED
Enable
> Disable
Figure 24

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
