Taylor C723 Service Manual

20
Controls, Systems and Operations
Model C723
Enable the AUTO START TIME by selecting the UP
arrow key to move the arrow to “Enable.” Press the
SEL key to advance to the next screen.
(See Figure 25.)
AUTO START TIME
00:00
Change
> Exit
Figure 25
Program the AUTO START TIME by selecting the
UP arrow key to move the arrow to “Change.” Press
the SEL key to advance to the next screen.
(See Figure 26.)
AUTO START TIME
00:00
Figure 26
Use the arrow keys to program the AUTO START
TIME by increasing or decreasing the hour setting
above the cursor. Press the SEL key to advance the
cursor and program the minutes setting. Select the
SEL key to return to the previous screen with the
new time setting displayed. Select the SEL key to
exit the screen and return to the Manager's Menu.
The STANDBY option is used to manually place
either side of the machine in the Standby mode
during long, no draw periods. Select the STANDBY
screen from the Manager's Menu. Press the SEL
key to activate Standby.
Discontinue Standby operation by exiting the
Manager's Menu and selecting the AUTO mode.
(See Figure 27.)
STANDBY MODE
LEFT
RIGHT
> Exit
Figure 27
The MIX LEVEL AUDIBLE option, when enabled,
will alert the operator with an audible tone when
there is a mix low or mix out condition. The following
screen is displayed upon selecting this option.
(See Figure 28.)
MIX LEVEL AUDIBLE
ENABLED
> Enable
Disable
Figure 28
Disable the audible tone feature by selecting the UP
arrow key to move the arrow to “Disable.” Select the
SEL key to save the new setting and return to the
Manager's Menu. The control panel icons for Mix
Low and Mix Out will illuminate as the mix level
drops in the hopper, but the audible tone will be
disabled.
The FAULT DESCRIPTION screen lists any faults
detected by the control and allows the manager to
clear them from the system. Faults are displayed on
the second and/or third line. (See Figure 29.)
FAULT DESCRIPTION
L: Beater Overload
R: Beater Overload
Figure 29
Pressing the SEL key displays the next fault or
returns to the Manager's Menu if no other faults
exist. Pressing the SEL key any time faults are
displayed will clear corrected faults upon returning to
the Manager's Menu. Press the Menu key to return
to the Manager's Menu.

Taylor C723 Specifications

General

Type	Soft Serve Freezer
Mix Flow	Gravity
Number of Flavors	2 + Twist
Electrical	208-230/60/1
Freezing Cylinder Size	3.4 qt (3.2 L)
