TO THE INSTALLER
1-3
087482-M
To the Installer
1
Electrical Hookup Installation
(60 Cycle, 1 Ph, Supplied with Cord and Plug)
This freezer is supplied with a three-wire cord and
grounding plug for connection to a single-phase, 60-
cycle, branch circuit supply. This unit must be plugged
into a properly grounded receptacle. For example, the
cord and plug provided for 115/60/1 is 20 A; therefore,
the wall outlet must also be 20 A. Check the data label,
located on the side panel, for electrical specifications.
Permanent wiring may be employed if required by local
codes. Instructions for conversion to permanent wiring
are as follows:
• Be sure the freezer is electrically disconnected.
• Remove the appropriate panel and locate the
small electrical box at the base of the freezer.
• Remove the factory-installed cord and strain
relief bushing.
• Route incoming permanent wiring through 7/8
in. (22 mm) hole in base pan.
• Connect two power supply leads. Attach ground
(earth) wire to the grounding lug inside the
electrical box.
• Be sure the unit is properly grounded before
applying power.
Beater Rotation
NOTICE! Beater rotation must be clockwise as
viewed looking into the freezing cylinder.
Refrigerant
CAUTION! In consideration of our environment,
Taylor uses only earth-friendly HFC refrigerants. The
HFC refrigerant used in this unit is R404A. This
refrigerant is generally considered nontoxic and
nonflammable, with an ozone depleting potential (ODP)
of zero (0). However, any gas under pressure is
potentially hazardous and must be handled with caution.
NEVER fill any refrigerant cylinder completely with liquid.
Filling the cylinder to approximately 80% will allow for
normal expansion.
CAUTION! Use only R404A refrigerant that
conforms to the AHRI standard 700 specification. The
use of any other refrigerant may expose users and
operators to unexpected safety hazards.
WARNING! Refrigerant liquid sprayed onto the
skin may cause serious damage to tissue. Keep eyes
and skin protected. If refrigerant burns should occur,
flush immediately with cold water. If burns are severe,
apply ice packs and contact a physician immediately.
NOTICE! Taylor reminds technicians to be
aware of and in compliance with local government laws
regarding refrigerant recovery, recycling, and reclaiming
systems. For information regarding applicable local laws,
please contact your local authorized Taylor distributor.
IMPORTANT! R404A refrigerant used in
conjunction with polyolester oils is extremely moisture
absorbent. When opening a refrigeration system, the
maximum time the system is open must not exceed 15
minutes. Cap all open tubing to prevent humid air or
water from being absorbed by the oil.
