103
McDonald's Intelligap Grills
Parts
150721
C834 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 PLATEN A.-3100W X73333-75S
2 KIT A.-GREASE SHIELD X78330-SER
2a FASTENER-SNAP IN 1/4X15/16 078329
2b SHIELD-GREASE 078285
3 PANEL-BACK TW0 SPEED FAN 072959
4 PANEL A.-BACK SERVICE X72951
5 SCREW-10-32X3/8 SLTD TRUS 024298
6 PANEL A.-SIDE UPPER *RT X74127
7 SCREW-10-32X3/8 UNSL HWH 039381
8 PANEL-SIDE *RIGHT 074111
9 NUT-JAM 1 1/2-12 STEEL 073594
10 CASTER-5" 7-5/8 STEM RIGID 078377
11a-
11g
LON CONTROL USED S/N M5057035 &
PRIOR
11 CONTROL A.-LON X73770-26
11a CONTROL-GATEWAY-LON X72848-SER
11b FILTER-CORCOM 2VR1 032567
11c SCREW-8X1/4 SLTD HEX 009894
11d FILTER-EMI-LINE-250V50/60HZ
LON
073245
ITEM DESCRIPTION PART NO.
11e SCREW-10X3/8 SLOTTED HEX 015582
11f TRANS.-CONT.-40VA 208/240V 053072
11g SCREW-6-32X5/8 UNSLTD 041363
12 SCREW-10-32X5/8 UN SL HWH 039382
13 CONTROL A.-BOX
(SEE PG 116)
X72514-40
14 CASTER-5" 7-5/8 SWIVEL
W/LOCK
073240
15 DOOR A.-CONTROL X72485
16 BUTTON-OPERATOR-BLACK 076012
17 GUARD-LENSE 075288
18 BUTTON-OPERATOR-RED 076011
19 PANEL A.-LIGHT X78845
20 COMPRESSOR A.
(SEE PG 161)
X73288-27
21 PANEL-SIDE *LEFT 074110
22 PANEL A.-SIDE UPPER *LT X74126
23 SWITCH-ROCKER-DPST-10A 076989-WP
24 CONTROL-DISPLAY X72491-SER
To Next Page
