7
McDonald's Intelligap Grills
Introduction
150520
Model C834 Specifications
See the data label for exact specifications.
Electrical
Standard is 400/50/3 phase.
Three dedicated electrical connections are required;
two, three phase and one interlock/control single
phase. See electrical chart for proper electrical
requirements. Manufactured to be permanently
connected. Consult your KES or local Taylor
distributor for cord and receptacle specifications as
local codes allow.
Electrical Total
Amp
Total
KW
Interlock/
Control
Voltage
Interlock
Fuse
Size
208/60/3 56 20 120/60/1 7A
220/380/60/3 31 20 230/60/1 4A
400/50/3n~4w 29 20 230/50/1 4A
Dimensions
Width: 38” (965 mm)
Depth: 32-3/4” (832 mm)
Height : 49-9/16 to 54-9/16” (1258 to 1385 mm)
Cooking Surface Height: 29 to 34” (737 to 864 mm)
Floor Clearance: 4-1/4 to 9-1/4” (108 to 235 mm)
Approximate Weight
Net: 758 lbs. (343.8 kgs.)
Crated: 872 lbs. (395.5 kgs.)
Volume
53.7 cu. ft. (1.52 cu. m.)
Figure 2
