12
Introduction
McDonald's Intelligap Grills
150520
Model C844 Specifications
See the data label for exact specifications.
Electrical
Three dedicated electrical connections are required;
two, three phase and one interlock/control single
phase. See electrical chart for proper electrical
requirements. Manufactured to be permanently
connected. Consult your KES or local Taylor
distributor for cord and receptacle specifications as
local codes allow.
Electrical Total
Amp
Total
KW
Interlock/
Control
Voltage
Interlock
Fuse
Size
208/60/3 63 22.5 120/60/1 7A
220/380/60/3 38 24.9 220/60/1 4A
400/50/3n~ 32 22.0 230/50/1 4A
220/50/60/3 64 24.2 220/50/60/1 7A
Dimensions
Width: 38” (965 mm)
Depth: 34-15/16” (887 mm)
Height : 50-1/2 to 55-1/2” (1283 to 1410 mm)
Cooking Surface Height: 29 to 34” (737 to 864 mm)
Floor Clearance: 5-3/16 to 10-3/16”
(132 to 259 mm) (Casters may be adjusted.)
Approximate Weight
Net: 870 lbs. (394.6 kgs.)
Crated: 945 lbs. (428.6 kgs.)
Volume
53.7 cu. ft. (1.52 cu. m.)
Figure 7
