McDonald's Intelligap Grills
Parts
150720
C838 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 PANEL-SIDE 073345-L
2 SCREW-10-32X3/8 SLTD TRUS 024298
3 SCREW-10-32X3/8 UNSL HWH 039381
4 PANEL-SIDE UPPER-LT 073352
5 PLATEN A.-SERVICE X73333-75
6 KIT A.-GREASE SHIELD
(includes items 6a & 6b)
X78330-SER
6a FASTENER-SNAP IN 1/4X15/16 078329
6b SHIELD-GREASE 078285
7 PANEL A.-BACK SERVICE X83555
8 CONNECTOR-MATE LOCK 044823
9 NUT-LOCKING CONDUIT 1/2" 078327
10 HARNESS A.-BACK PNL X74158
11 CAP-PROTECTIVE-PLASTIC 053889
12 PANEL-SIDE UPPER-RT 073353
13 PANEL-SIDE 073345-R
14a-
14f
LON CONTROLS USED S/N M5057035 &
PRIOR
14 CONTROL A.-LON
ITEM DESCRIPTION PART NO.
14a CONTROL-GATEWAY-LON X72848-SER
14b FILTER-CORCOM 2VR1 032567
14c SCREW-8X1/4 SLTD HEX 009894
14d FILTER-EMI-LINE-250V50/60HZ 073245
14e SCREW-10X3/8 SLOTTED HEX 015582
14f TRANS.-CONT.-40VA 208/240V 053072
15 SCREW-10-32X5/8 UN SL HWH 039382
16 DOOR A.-CONTROL X83525
17 CONTROL-DISPLAY X72491-SER
18 SWITCH-ROCKER-DPST-10A 076989-WP
19 BUTTON-OPERATOR-BLACK 076012
20 GUARD-LENSE 075288
21 PANEL A.-SWITCH X83535
22 BUTTON-OPERATOR-RED 076011
23 LABEL-CONTROL PANEL 075699-SYM
24 CONTROL A.-BOX
(SEE PAGE 124)
X83099-27
25 COMPRESSOR A.-AIR
(SEE PAGE 163)
X83304-34
