McDonald's Intelligap Grills
Parts
150721
C842 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 PLATEN A.-2600W *208V X73467-23
2 KIT A.-GREASE SHIELD* X78330-SER
2a FASTENER-SNAP IN 1/4X15/16 078329
2b SHIELD-GREASE 078285
3 PANEL A.-BACK PNL X72958-SER
3a CAP-PROTECTIVE-PLASTIC 053889
3b HARNESS A.-BACK PNL X74158
3c NUT-LOCKING CONDUIT 1/2" 078327
3d CONNECTOR-MATE LOCK 044823
3e PANEL-BACK 2 SPEED FAN 072959
4 PANEL A.-BACK SERVICE X72951
5 SCREW-10-32X3/8 SLTD TRUS 024298
6 COMPRESSOR A.-AIR
(SEE PG 164)
X72724-12
7 NUT-JAM 1 1/2-12 STEEL 073594
8 SCREW-10-32X3/8 UNSL HWH 039381
9 PANEL A.-SIDE UPPER X72965
10 PANEL-SIDE*RIGHT* 072968
11 CASTER-5" 7-5/8 STEM 078377
12a-
12d
LON CONTROLS USED M5057035 & PRIOR
12
CONTROL A.-LON (60HZ) X72805
CONTROL A.-LON (50HZ) X72805-26
12a
CONTROL-GATEWAY-LON
(60HZ)
X72848-SER
CONTROL-GATEWAY
*CENELEC (50HZ)
X72848SER1
ITEM DESCRIPTION PART NO.
12b SCREW-6-32X5/8 UNSLTD 041363
12c SCREW-8X1/4 SLTD HEX 009894
12d FILTER-CORCOM 2VR1 032567
12e SCREW-10X3/8 SLOTTED HEX 015582
12f TRANS.-CONT.-40VA 208/240V 053072
12g FILTER-EMI-LINE-250V50/60 073245
13 SCREW-10-32X5/8 UN SL HWH 039382
14 CONTROL A.-UPPER
(SEE PG 128)
X72827-12
15 CONTROL A.-LOWER
(SEE PG 126)
X72707-23
16 DOOR A.-CONTROL X72431
17 CONTROL A.-SWITCH
(SEE PG 136)
X72433
17a BUTTON-OPERATOR-RED 076011
17b BUTTON-OPERATOR-BLACK 076012
17c PANEL A.-LIGHT X72434
18 CASTER-GRILL 5" SWIVEL
W/LOCK
073240
19 PANEL-SIDE*LEFT* 072967
20 PANEL A.-SIDE UPPER*LT X72962
21 CONTROL-DISPLAY X72491-SER
22 SWITCH-ROCKER-DPST-10A 076989-WP
