113
McDonald's Intelligap Grills
Parts
150721
C844 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1
PLATEN A.-2450W 230V SERV
(STANDARD)
X73183-75
PLATEN A.-2450W SERV
(WRAP AROUND)
X73599-75
2 KIT A.-GREASE SHIELD X78330-SER
2a FASTENER-SNAP IN 1/4X15/16 078329
2b SHIELD-GREASE 078285
3 PANEL-BACK 2 SPEED FAN 072959
4 PANEL A.-BACK SERVICE X72951
5 SCREW-10-32X3/8 SLTD TRUS 024298
6 COMPRESSOR A.-AIR
(SEE PG 164)
X72724-27
7 NUT-JAM 1 1/2-12 STEEL 073594
8 PANEL A.-SIDE UPPER*RT X72788
9 SCREW-10-32X3/8 UNSL HWH 039381
10 PANEL-SIDE *RIGHT 072791
11 CASTER-5" 7-5/8 STEM 078377
12a-
12g
LON CONTROLS USED S/N M5057035 &
PRIOR
12 CONTROL A.-LON X72805-26
12a CONTROL-GATEWAY
*CENELEC
X72848SER1
ITEM DESCRIPTION PART NO.
12b SCREW-6-32X5/8 UNSLTD 041363
12c SCREW-8X1/4 SLTD HEX 009894
12d FILTER-CORCOM 2VR1 032567
12e SCREW-10X3/8 SLOTTED HEX 015582
12f TRANS.-CONT.-40VA 208/240V 053072
12g FILTER-EMI-LINE-250V50/60 073245
13 SCREW-10-32X5/8 UN SL HWH 039382
14 CONTROL A.-UPPER
(SEE PG 129)
X72889-40
15 CONTROL A.-LOWER
(SEE PG 126)
X72707-75
16 DOOR A.-CONTROL X72431
17 PANEL A.-LIGHT X72434
18 CASTER-GRILL 5" SWIVEL
W/LOCK
073240
19 PANEL-SIDE *LEFT 072790
20 PANEL A.-SIDE UPPER*LT X72786
21 SWITCH-ROCKER-DPST-10A 076989-WP
22 CONTROL-DISPLAY X72491-SER
23 BUTTON-OPERATOR-RED 076011
24 BUTTON-OPERATOR-BLACK 076012
