121
McDonald's Intelligap Grills
Parts
Control A.-Box - X73133-12 (C835 - 60 Hz) Parts Identification
ITEM DESCRIPTION PART NO.
1 CONTROL-MOTOR X72436-SER
2 SCREW-6X3/4 SLTD ROUND A 039113
3 SWITCH-PRESSURE 074314
4 SCREW-6X3/8 SLTD HEX 001825
5 BUSHING-SNAP 5/8ID X 3/4OD 017462
6 PANEL-PCB MOUNTING-L 072524
7 SCREW-10-32X3/8 SLTD HEX 044617
8 TUBE-NYLOBRADE 1/4 X 7/16 020568-14
9 CLAMP-HOSE 7/16-WIRE 051742
10 CONTROL-IGNITOR UTC X70301-02S
11 STANDOFF-NYLON 6-32 040280-020
12 NUT-6-32 HEX NUT NYLON 045852
13 SCREW-8X1/2 SLTD HEX 075763
14 RELAY-3P-40A 110/120 COIL 050841-12
15 PLUG A.-IGNITOR X79819
16 BUSHING-SNAP 15/16 ID 023396
17 HARNESS-RELAY/PCB 073168
18 SCREW-10-32X1/2 SERRATED 020982
19 BRACKET-RELAY-HARNESS 074237
20 CONNECTOR-BX 3/8 45 DEG 010687
21 BLOCK-TERMINAL 7P GREEN 024156
22 NUT-10-32 WHIZ FLANGE LOC 020983
23 NUT-1/4-20 WHIZ FLANGE LOC 017523
24 RELAY A.-3 HEATER X74213
25 LABEL-BURNER AIR ADJUST 079501
ITEM DESCRIPTION PART NO.
26 PANEL-PCB MOUNTING-R 072523
27 HARNESS-PCB/GR SWITCH 072529
28 BLOCK-TERMINAL 3P 20A
300V
051331
29 HARNESS-PCB/LOGIC 072527
30 FILTER-CORCOM 2VR1 032567
31 BUSHING-SNAP 1-5/8ID X 2 OD 043637
32 BLOCK-TERMINAL 4P 1,2,L1,N 051647
33 SCREW-8X1 1/4 PHLP HD RD 039420
34 HOLDER-FUSE-15 A, 250 V 076299
35 BRACKET-FUSE 079867
36 BLOCK-TERMINAL 2P .25 SPD 051644
37 TRANS.-100VA 120/208/240 079800
38 LUG-GROUNDING 4-14GA
WIRE
017667
39 SCREW-1/4-20X5/8 SERRATED 017522
40 LUG-GROUNDING 260 W/GR.
SCREW
020928
41 LABEL-COPPER COND ONLY 025948
42 LABEL-WIRING *CONTR 079538-12
43 FILTER A. X79256-L
* HARNESS A.-COMP. VALVE X73145
* HARNESS A.-CNTL BOX X74157
* HARNESS A.-GAS VALVE X79511
* HARNESS A.-COMP/TB X79503
* FUSE 7 AMP 079837-070
*NOT SHOWN
