McDonald's Intelligap Grills
Parts
Control A.-Box - X73133-40 (C835 - 50 Hz) Parts Identification
ITEM DESCRIPTION PART NO.
1 CONTROL-MOTOR X72436-SER
2 SCREW-6X3/4 SLTD ROUND A 039113
3 SWITCH-PRESSURE 074314
4 SCREW-6X3/8 SLTD HEX 001825
5 BUSHING-SNAP 5/8ID X 3/4OD 017462
6 PANEL-PCB MOUNTING-L 072524
7 SCREW-10-32X3/8 SLTD HEX 044617
8 TUBE-NYLOBRADE 1/4 X 7/16 020568-12
9 CLAMP-HOSE 7/16-WIRE 051742
10 TUBE-NYLOBRADE 1/4 X 7/16 020568-3
11 FITTING-.25 BARB W/.030 ORF. 079803
12 CONTROL-IGNITION 24VAC 079840-03
13 SCREW-6-32X3/8 SLTD HWH 042022
14 SCREW-8X1/2 SLTD HEX 075763
15 RELAY-4P-40A 200/240 COIL 050869-27
16 FILTER A.-*WHT/BLK X78996-40
17 BLOCK-TERMINAL 7P GREEN 024156
18 BUSHING-SNAP 15/16 ID 023396
19 CONNECTOR-BX 3/8 45 DEG 010687
20 BUSHING-SNAP 1-5/8ID X 2 OD 043637
21 NUT-10-32 WHIZ FLANGE LOC 020983
22 NUT-1/4-20 WHIZ FLANGE LOC 017523
23 HARNESS-RELAY/PCB*HV 073237
24 SCREW-10-32X1/2 SERR HWH 020982
25 BRACKET-RELAY-HARNESS 074237
26 PANEL-PCB MOUNTING-R 072523
27 HARNESS-PCB/GR SWITCH 072529
28 HARNESS-PCB/LOGIC 072527
ITEM DESCRIPTION PART NO.
29 FILTER-CORCOM 2VR1 032567
30 BLOCK-TERMINAL 4P 1,2,L1,N 051647
31 SCREW-8X1 1/4 PHLP HD RD 039420
32 HOLDER-FUSE-15 A, 250 V 076299
33 BRACKET-FUSE 079867
34 BLOCK-TERMINAL 2P .25
SPADE
051644
35 TRANS.-100VA 120/208/240 PRI 079800
36 RELAY A.-3 HEATER X74213
37 LUG-GROUNDING 4-14GA
WIRE
017667
38 SCREW-1/4-20X5/8 SERRATED 017522
39 LUG-GROUNDING 260 W/GR.
SCREW
020928
40 HARNESS A.-COMP. VALVE X73145
41 HARNESS A.-GAS VALVE X79511-40
42 HARNESS A.-COMP/TB X79503
43 PLUG A.-IGN CNTL X71391
44 LABEL-BURNER AIR ADJUST 079501
45 RELAY-DPDT 100UA TO 7A
1/8HP
052111-03
46 BLOCK-TERMINAL 3P 20A
300V
051331
47 TRANS.-CONT.-80VA 230V/24V 059993
48 VARISTOR A.-280VAC X34664
49 SCREW-6X5/16 SLTD ROUND 013646
50 LABEL-COPPER COND ONLY 025948
51 LABEL-WIRING *CONTR 079538-40
