McDonald's Intelligap Grills
Parts
Control A.-Upper - X73384-12 (C845 - 60 Hz) Parts Identification
ITEM DESCRIPTION PART NO.
1 CONNECTOR-BX 3/4 STR-2
SCREW
031231
2 BLOCK-TERMINAL 2P .25 SPD 073033
3 SCREW-8X1/2 SLTD HEX WASH 075763
4 HARNESS-BLOWER 073420
5 HARNESS-COMPRESSOR 073422
6 SUPPLY-POWER-10W 12VDC 073336
7 BASE-TERMINAL 500187-4
8 SCREW-10X3/8 SLTD HEX WSH 015582
9 HARNESS-POWER SUPPLY 073436
10 CLAMP-CABLE 3/8" PLASTIC 000290
11 SCREW-6-32X3/8 SLTD HWH 042022
12 HARNESS-GAS VALVE 073426
13 HARNESS-PRESSURE SWITCH 073444
14 HARNESS-12V-POSITIVE-BRD 073428
15 HARNESS-12V-NEGATIVE-BRD 073427
16 HARNESS-TRANS A.-115V 073454
17 SWITCH-PRESSURE 074314
18 HARNESS-IDC BOARD 073429-R
19 HARNESS-IDC BOARD 073429-M
20 HARNESS-IDC BOARD 073429-L
21 BRACKET-FUSE 079867
22 HOLDER-FUSE-15 A, 250 V 076299
23 HARNESS-SWITCH 073424
24 LABEL-COPPER COND ONLY 025948
25 SCREW-1/4-20X5/8 SERRATED 017522
ITEM DESCRIPTION PART NO.
26 LUG-GROUNDING 4-14GA WIRE 017667
27 LABEL-PROTECTIVE EARTH
GROUND
017669
28 BLOCK-TERMINAL 1P 073423
29 RELAY-3P-50A 110/120 COIL 051890-12
30 FILTER A.-*WHT/BLK X79256
31 RELAY-SS 25A NON-ALARM
240 V
074210-02
32 HARNESS-SSR-MIDDLE 073096
33 HARNESS-SSR-RIGHT 073097
34 BLOCK-TERMINAL 3P 20A 300V 051331
35 SCREW-10-32X1/4 UNSL. HEX. 057361
36 TUBE-NYLOBRADE 1/4ID X 7/16 020568-
37 CLAMP-HOSE 7/16-WIRE 051742
38 STANDOFF-NYLON 6-32 SNP 040280-020
39 NUT-6-32 HEX NUT NYLON 045852
40 CONTROL-IGNITOR UTC 070301-02
41 SCREW-8X1 1/4 PHLP HD RD B 039420
42 BLOCK-TERMINAL 4P 1,2,L1,N 051647
43 LABEL-WIRING *CONTR 079538-12
44 SCREW-10-32X1/2 UNSL HWH 049877
45 HARNESS-SSR-LEFT 073095
46 SCREW-10-32X1/2 SERRATED 020982
47 BUSHING-SNAP 1-3/8ID X 1-3/4 027712
48 PLATE-HEATSINK *GAS 072980
