Taylor Intelli Gap User Manual

140
Parts
McDonald's Intelligap Grills
Platen A.-Serv - X73333-23 (60 Hz) -75 (50 Hz) (C832/C834/C835/C836/C838)
Parts Identification
ITEM DESCRIPTION PART NO.
1 INSULATION-CER FBR 072459
2 THERMOCOUPLE-K TYPE SS 079622
3 SHIELD-HEAT 072460
4 SHIELD-PLATE SHROUD 072465
5 SCREW-10-32X7/16 LAT HD 065717
6 SHIELD-PLATE TUBE INNER 072467-1
7 NUT-10-32 WHIZ FLANGE LOCK 020983
8 BAR A.-RELEASE X73315
9 O-RING-1-1/16OD X .103W 052733-118
10 SHIELD-COUPLING FRONT 072926
11 SHIELD-PLATE TUBE 072467
12 SHIELD-PLATE SHROUD-
OUTER
072466
13 SEALANT-GORE-TEX 1/4 R700033
ITEM DESCRIPTION PART NO.
14 SHIELD-COUPLING REAR 072927
15 O-RING-1-3/16OD X .103W 052733-120
16 CABLE-ADJUST-PLATEN 072458
17 NUT-#10-32 KEPS 18-8 SS 059169
18 INSULATOR-TEFLON-2 HOLE 079810
19 SCREW-8-32X5/16 SLTD RND 017552
20 WASHER-#8 EXTERNAL TOOTH
LOCK
000964
21
CONTROL-LIMIT W/SCREWS
(60 HZ)
078721
CONTROL-HI-LIMIT 550F
(50 HZ)
074165
22 SCREW-12-24X1/2 TORX DRIVE 058720
23 WASHER-1/4 EXTERNAL
TOOTH LOCK
000656
