TBS TANGO FPV REMOTE - Remote Control Channel Mapping

Remote Control Channel Mapping
The channel arrangement of the PPM output to the RF module is dependant on the kind of flight controller
that is hooked-up on the receiver side.
In the configuration menu, you can change the mapping by changing the model type to match your particular
setup.
PPM
Channel
Flight Control Model
DJI
3DR
BLADE
CROSSFIRE
TAULABS
1
AIL
AIL
THR
AIL
AIL
2
ELE
ELE
AIL
ELE
ELE
3
THR
THR
ELE
THR
THR
4
RUD
RUD
RUD
RUD
RUD
5
Tuner L (E)
3-Pos Right (D)
3-Pos Right (D)
3-Pos Right (D)
3-Pos Right (D)
6
Tuner R (F)
Tuner R (F)
2-Pos Right (C)
2-Pos Right (C)
2-Pos Right (C)
7
3-Pos Right (D)
2-Pos Right (C)
2-Pos Left (A)
2-Pos Left (A)
2-Pos Left (A)
8
2-Pos Right (C)
2-Pos Left (A)
3-Pos Left (B)
3-Pos Left (B)
3-Pos Left (B)
9
3-Pos Left (B)
Tuner L (E)
Tuner L (E)
Tuner L (E)
Tuner L (E)
10
2-Pos Left (A)
3-Pos Left (B)
Tuner R (F)
Tuner R (F)
Tuner R (F)
