TC-Helicon Voicelive 2 User Manual

mono. LEFT puts the left side out of phase with the right
which is normal phase and vice versa for the RIGHT
value. BOTH puts both sides out of phase with their
respective sides’ correct phase while remaining in phase
with each other.
DLY L / DLY R
Sets the left and right delay times. Up to 50 ms of delay
is available on the left and right delay lines to create
effects from flange to slapback.
FEEDBACK L / FEEDBACK R
Re-introduces a portion of the audio output signal of the
μMod block back to the input to create flanges, tube and
chorus effects.Values above 90 add a high amount of
gain and cause distortion and higher audio levels.
PHASE
This defines the modulation phase which is the phase
relationship between the left and right modulation LFOs
(oscillators). In a flange style, for example, setting this to
0 degrees puts all of the effect in the center while setting
it to 180 degrees pulls the effect far into the stereo field.
WAVE
This lets you choose the modulation waveform from
Square,Triangle or Sine to vary the periodic nature of
the modulation effect.
XFL L / XFL R
These send cross feedback from the left and right delay
lines (XFL L) and from right to left (XFR L). Cross
feedback returns the delayed audio to the opposite
side’s delay line. This can produce interesting stereo
effects.
LOWCUT L / LOWCUT R
HICUT L / HICUT R
These steep highpass (LOWCUT) and low pass
(HIGHCUT) filters control the bandwidth of the μMod
feedback paths. These are very useful for tailoring Flange
effects.
LEAD TO UMOD
Sets the amount of lead voice sent into the μMod block.
The Edit Menu: μMOD Tab
55

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
