TC-Helicon Voicelive 2 User Manual

HI FACTOR
This allows you to raise or lower the level of the high
band of the Reverb tail independently.
EARLY REFLECTIONS / TAIL LEVEL
These parameters allow you to attain the right balance
between reflections you would hear from close surfaces
(EARLY REFLECTIONS) with those from surfaces
further away (TAIL LEVEL). The settings for the
early reflections in each style are slightly different but
non-editable.
DUCKING
When DUCKING is set to ON, the Reverb block’s
output will be reduced while you are singing. At the end
of a sung phrase, the effects return to the level you set,
increasing the clarity of your vocals while still sounding
very “wet”. The amount of attenuation and attack time
for ducking are set with the DUCKING AMOUNT and
DUCKING TIME parameters further down in this menu.
DIFFUSE
Also known as Diffusion, this is a very subtle parameter
used to simulate and control the density of the reflections
inherent in real acoustic spaces. Low DIFFUSE values
(-25 to 0) are intended to introduce more discrete
echo-like motion to the tail where high values (0 to 25)
make the tail smoother-sounding.
PRE DLY
Pre Delay introduces a short (up to 100 ms) delay
between the dry audio signal and the onset of reverb
to help simulate larger spaces and to provide audio
separation between the dry signal and the reverb effect.
SPEED
This controls the rate of pitch modulation set by the
DEPTH parameter. This modulation adds complexity
and slight chorusing between the reverb tail and the
input voice. The values range from -25 to 25.
DEPTH
This controls the amount of pitch modulation applied to
the reverb tail. The values range from -25 to 25.
The Edit Menu: REVERB Tab
61

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
