TC-Helicon Voicelive 2 User Manual

OUTPUT LEVEL RANGE
Configures the maximum stereo analog output (XLR,
¼” and headphone) level. Set this value to MIC or LINE
when connecting to mic or line level inputs on a mixer
respectively. This will minimize distortion and noise.
The +6 and +12 options raise the respective output
levels by reducing internal headroom. If you hear
distortion on singing peaks when otherwise connected
correctly (MIC level output to a mic input, LINE to a line
input), use a lower level output option.
Note that the LINE +12 option is the highest output
level and it is effective for increasing headphone output
level in loud environments.
GUITAR MUTE
Mutes the guitar signal in the main outputs when no jack
is connected to the GUITAR THRU jack. This allows the
guitar dry signal to be mixed externally. The guitar signal
still feeds the NATURALPLAY harmonies and tuner.
PAN
Sets the stereo position of the dry guitar signal.
MIC/LINE PHASE
Selects between NORMAL and INVERTED to help
reduce feedback in live performance. This feature is
intended to work with low and low mid frequency
feedback tones. The mic must be in a stationary position
in relation to the monitor.
The Setup Menu: I/O Tab
85

TC-Helicon Voicelive 2 Specifications

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Power

external power supply mains voltage	100 to 240 VAC, 50 to 60 Hz
power consumption	<14 W

Analog Inputs

mic input impedance	2.14/1.07 kOhm
line input impedance	13/6.5 kOhm
guitar input impedance	1 MOhm

Analog Outputs

output impedance	100/50 Ohm
output range	16 dBu / 0dBu
dynamic range	> 109 dB, 20 Hz to 20 kHz

Weight and Dimensions

dimensions	13.8" x 3" x 8.5" (350 x 76 x 216)
weight	5 lb. (2.3 kg)
