30
HANGING THE CASSETTE UNIT
Adjust the under side of the gasket
so it sits 90mm above the ceiling.
Overhang the cassette unit above
the ceiling, slotting the bars into the
brackets on the cassette unit and
tightening into position, ensuring
that the unit is level.
Hanging Bolt
Nut (Up Side)
Gasket (Up Side)
Installing Ear
Nut (Under Side)
Gasket (Under Side)
Underside of Ceiling
90mm
