Indoor Unit- TAC-07CSC/K , TAC-09CSC/K
No. Part No. Part Name Q’ty Remark
1 1080030008 Installation Plate 1
2 1210320107 Base 1
3 1070020016 Cross Fan 1
4 1070100010 Bearing Mount 1
5 1210320601 Evaporator 1
6 1070320103 Water Drainage Assembly 1
7 1070320105 Vertical Vane Assembly 2
8 1070320107 Face Frame 1
9 1070320112 Screw Cover 2
10 1090320102 Display PCB 1
11 1070320115 Display PCB Box 1
12 1070320109 Air Filter 2
13 1070321501 Front Panel 1
14 1070251001 Display PC Board Cover 1
15 1170120047 Power Supply Cord 1
16 1070320104 Vane 1
17 1070110008 Drainage Hose 1
18 1070040006 Electrical Box Cover 1
19 1070040004 Cable Clamp 1
20 1170200039 Terminal 1
21 1070250109 Terminal Fixing Board 1
22 1170020011 Vane Motor 1
23 1090320102 Main PCB 1
24 1110040001 Sensor Holder 1
25 1070320113 Electrical Box 1
26 1070320111 Indoor Motor Cover 1
27 1170030047 Indoor Motor 1
28 1170240001 Transformer 1
29 1170230001 Pipe Temp. Sensor & Room
Temp. Sensor Assembly
1
30 1070320101 In And Out Pipe Fixer 1
31 1090010071 Remote Controller 1
31 1073030303 Remote Controller Supporter 1
32 1190350102 Indoor Carton 1
33 1190060005 Left Foaming 1
34 1190060006 Right Foaming 1
Not shown in Explosion
view
