TCL Air Conditioner Service Manual
51
Outdoor Unit- TAC-18CHSC/K
No. Part No. Part Name Q’ty Remark
1 1084530501 Grille 1
Optional
2 1084530504 Top Cover 1
3 1210700202 Condenser 1
4 1084530510 Outdoor Motor Supporter 1
5 1170040063 Outdoor Motor 1
6 1070030017 Propeller Fan 1
7 1084530516 Left Plate 1
8 1084530514 Front Plate 1
9 1084530515 Fan Guard 1
10 1210700101 Capillary Assembly 1
11 --------------- Compressor and its Accessories 1
12 1210700201 4-way Vane assembly 1
13 1214561809 Base 1
14 1120120011 Two-way Valve 1
15 1084530502 Valve Supporter 1
16 1120130013 Three-way Valve 1
17 1084530503 Right Plate 1
18 1074530503 Electrical Box Cover 1
19 1084561802 Electrical Parts Box 1
20 1080010006 Capacitor Strip 1
21 1170100007 Compressor Capacitor 1
22 1170100030 Fan Motor Capacitor 1
23 1170200036 Terminal 1
24 1074060118 Cable Clamp 1
25 1174561803 Compressor Power Supply
Wiring
1
26 1173570502 Earthing Wiring 1
27 1174561801 AC Contactor 1
28 1174530303 Outdoor Pipe Sensor 1
29 1190070003 Base Carton 1
30 1190070013 Cabinet Carton 1
31 1190070004 Cover Carton 1
Not shown in the Explosion
view.
Consist dryfilter forthe
To Next Page
