TCL Air Conditioner Service Manual
50
Outdoor Unit- TAC-18CHS/K
No. Part No. Part Name Q’ty Remark
1 1080050026 Grille 1
Optional
2 1080050011 Top Cover 1
3 1210500107 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040054 Outdoor Motor 1
6 1070030012 Propeller Fan 1
7 1080050001 Left Plate 1
8 1080050009 Front Plate 1
9 1080320112 Fan Guard 1
10 1213590201 Capillary Assembly 1
11 --------------- Compressor and its Accessories 1
12 1210500102 4-way Vane assembly 1
13 1210500106 Base 1
14 1120120016 Two-way Valve 1
15 1080050003 Valve Supporter 1
16 1120130021 Three-way Valve 1
17 1080050002 Right Plate 1
18 1073551103 Electrical Box Cover 1
19 1080020002 Electrical Parts Box 1
20 1080010006 Capacitor Strip 1
21 1170100007 Compressor Capacitor 1
22 1170100027 Fan Motor Capacitor 1
23 1170200020 Terminal 1
24 1073570503 Up Cable Clamp 1
25 1073570502 Lower Cable Clamp 1
26 1173570501 Compressor Power Supply
Wiring
1
27 1173570502 Earthing Wiring 1
28 1174561802 Outdoor Pipe Sensor 1
29 1190070020 Base Carton 1
30 1190070002 Cabinet Carton 1
31 1190070021 Base Foaming 1
32 1190070022 Cover Forming 1
Not shown in the Explosion
view.
