Outdoor Unit- TAC-07CHSC/K, TAC-09CHSC/K
No. Part No. Part Name Q’ty Remark
1 1083510901 Grille 1
Optional
2 1080320105 Top Cover 1
3 1210320101 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040058 Outdoor Motor 1
6 1070030016 Propeller Fan 1
7 1080050001 Left Plate 1
8 1080320113 Front Plate 1
9 1080320112 Fan Guard 1
10 1210250605 Capillary Assembly 1
11 --------------- Compressor and its Accessories 1
12 1210250606 4-way Vane Assembly 1
13 1210320103 Base 1
14 1120120017 Two-way Valve 1
15 1080050003 Valve Supporter 1
16 1120130025 Three-way Valve 1
17 1080050002 Right Plate 1
18 1073551103 Electrical Box Cover 1
19 1080020001 Electrical Parts Box 1
20 1080010006 Capacitor Strip 1
21 1170100003 Compressor Capacitor 1
22 1170100032 Fan Motor Capacitor 1
23 1170200020 Terminal 1
24 1070040001 Cable Clamp(φ6) 1
25 1070040002 Cable Clamp(φ7) 1
26 1173570501 Compressor Power Supply
Wiring
27 1173570502 Earthing Wiring 1
28 1190070017 Base Carton 1
29 1190500302 Cabinet Carton 1
30 1190070019 Base Foaming 1
31 1190070018 Cover Forming 1
Not shown in the Explosion
view.
dry
Consist the filter for
