TCL Air Conditioner Service Manual
39
Indoor Unit- TAC-18CS/K ,TAC-18CSC/K , TAC-24CS/K , TAC-24CSC/K
No. Part No. Part Name Q’ty Remark
1 1080030001 Installation Plate 1
2 1073090101 Base 1
3 1070020014 Cross Fan 1
4 1070100010 Bearing Mount 1
5 1213090106 Evaporator 1
6 1073090104 Water Drainage Assembly 1
7 1073090106 Vertical Vane Assembly 2
8 1073090110 Face Frame 1
9 1073090111 Screw Cover 3
10 1093090102 Display PCB 1
11 1073090126 Display PCB Box 1
12 1073090112 Air Filter 2
13 1070500205 Front Panel 1
14 1070500208 Display PCB Cover 1
15 1073090122 Electrical Box Cover 1
16 1170120006 Power Supply Cord 1
17 1073090108 Vane A 1
18 1073090125 Vane B 1
19 1070110008 Drainage Hose 1
20 1070040003 Cable Clamp 2
21 1170020011 Vane Motor 1
22 1170200038 Terminal 2
23 1083090108 Terminal Fixing Board 1
24 1110040001 Sensor Holder 1
25 1093090201 Main PCB 1
26 1073090120 Indoor Motor Cover 1
27 1170030045 Indoor Motor 1
28 1093090201 Electrical Box 1
29 1173090107 Transformer 1
30 1170230001 Pipe Temp. Sensor & Room
Temp. Sensor Assembly
1
31 1090010071 Remote Controller 1
31 1073030303 Remote Controller Supporter 1
32 1130120008 Indoor Carton 1
33 1073030303 Left Foaming 1
34 1190250204 Right Foaming 1
35 1190060002 Middle Pasteboard Supporter 1
36 1190060021 Middle Foaming Supporter 1
Not shown in Explosion
view
To Next Page
