07/2015 11
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: hotline@tcsag.de • www.tcsag.de PI_ISW3130-uk 2 A
Ring tone selection
For 4 different incoming calls (door calls from 2 different front-door stations, floor call, in-
ternal call) different ring tones can be selected.
End voice communication. Press call OFF button for around 8 seconds.
Both LEDs are ON and an acknowledgement tone sounds, the ring tone selection
is activated.
By pressing the following buttons, a ring tone can be selected. You can choose be-
tween 13 different tones.
Select door ring tone
of the front-door
station*
Press the door release button until the required ring tone
sounds. The ring tone selected last is stored.
select door ring tone
of the floor door
Press the light switch button until the required ring tone
sounds. The ring tone selected last is stored.
select internal ring
tone
Press the control key until the required ring tone sounds.
The ring tone selected last is stored.
Short press the call OFF button.
Or: If no button is pressed for around 8 sec, the device end the ring tone selection
automatically. Both LEDs go out and an acknowledgement tone sounds, the ring
tone selection is deactivated.
* The ring tone is identical for all front-door stations and can be selected only identically for all.
To select a second ring tone it is necessary to activate the call distinction by changing the audio AS limit.
Changing the audio AS limit is possible only with the configuration software configo™.
Adjust the volume
Adjustable in 8 steps. A signal tone reproduces the adjusted ring tone volume when turn-
ing the ring tone volume control. If the adjustment is finished, the adjusted ring tone
sounds in the adjusted volume.
Turn the ring tone volume control when a conversation is estab-
lished (preset ex works: volume step 4 out of 8)
Turn the ring tone volume control when no conversation is estab-
lished (in stand-by; preset ex works: volume step 6 out of 8)
