TDK-Lambda LS Series - Page 13

1
・All specifications are subject to change without notice.
LS
100
LS100 Outline Drawing
157±0.3
7
5.5
8
?3.5
97±1
84.5±0.3
159±1
(4.5)
(24)
78±0.3
Ø3.5
(15.3)
9.5
8.3
81.7
7-M3.5
AC(L)
AC(N)
(FG)
-V
-V
+V
+V
SEE NOTE A
LED
VOLTAGE
ADJUSTMENT
(6.5)
Ø3.5
150±0.3
(22)
117±0.3
38±1
28.5
19
28.5
NAME PLATE
SEE NOTE B
SEE NOTE B
65
10.5 18±0.3
Ø3.5
L N V
ADJ
-V
-V +V
+V
H
NOTES
A. MODEL NAME NOMINAL OUTPUT VOLTAGE AND MAXIMUM OUTPUT CURRENT ARE SHOWN IN THE NAME PLATE IN ACCORDANCE
WITH THE SPECIFICATION.
B. M3 TAPPED & EMBOSSED & COUNTERSUNK HOLES (5) FOR CUSTOMER CHASSIS MOUNTING.
SCREW MUST NOT PROTRUDE INTO POWER SUPPLY BY MORE THAN 5mm.
LS100 Output Derating
*COOLING : CONVECTION COOLING
TB1
STANDARD MOUTINGLOAD(%)
Ta(°C)
-25 to +45
50
70
100
92 (3.3
＆
5V), 100 (OTHERS)
60
OUTPUT DERATING CURVE
LOAD(%)
120
100
80
60
40
20
0
Ta(°C)
-25 0 25 50 75 100
7045
3.3
＆
5
Ｖ
