Technical Information
Specification
MICROgarde 1 MICROgarde 2
Size (box) Non-PSU version: 210 x 135 x 47 mm
PSU Version 346 x 280 x 85 mm
Temperature
range
-5°C to +40°C
Power Non-PSU version: 10-14V @ 1A
PSU Version: Input: 100 to 240 VAC, 50-60Hz, 1.2A max.
Output: 13.8 VDC, 3A
PoE Version: Input: PoE+/PoE++ (IEEE 802.3af/bt).
Output: 13.8Vdc, 3A
Cards 10,000 with EXgarde software
Door control 0 or 1 0, 1 or 2
Communications RS232 (with built-in RS485 converter for downstream units)
RS485
Optional TCP/IP module adds 10/100mbps Ethernet port
Readers 0-2 0-4
Inputs 4 in total: 4 in total
4 spare in 0-door configuration 4 spare in 0-door
configuration
2 spare in 1-door configuration 2 spare in 1-door
configuration
0 spare in 2-door
configuration
Optional I/O module adds 4 inputs (and 2 relays)
Outputs 2 (30V, 2A rating) in total 2 (30V, 2A rating) in total
2 spare in 0-door configuration 2 spare in 0-door
configuration
1 spare in 1-door configuration 1 spare in 1-door
configuration
0 spare in 2-door
configuration
Optional I/O module adds 2 relays (and 4 inputs)
Features
(Controller)
0 or 1 door controller 0, 1 or 2 door controller
2 readers (using Clock&Data or
Wiegand 26-bit or Wiegand 37-
bit interface)
4 readers (using specified
TDSi readers) or 2 readers
(using Clock&Data or
Wiegand 26-bit or Wiegand
37-bit interface
