CHAPTER 1 INSTALLATION
17
Select and confirm the suitable fuse according to voltage used.
Power supply voltage
Fuse Capacity
250V
F 3.15A
1.7 Connection of Communication Cable
Besides power supply plug（POWER）, UV2600 has PC port and Acc port.
1.7.1 PC Port
UV2600 is controlled by UV Analyst software. Operation control and data
analysis are done by PC.
Using communication cable (standard accessory) provided by UV control
software, connect UV2600 PC port to computer COM port.
1.7.2 Acc Port
Many optional accessories can be configured on UV2600, including autosipper
controlled by PC.
Using communication cable provided by optional part, connect UV2600 Acc
port to the optional part.
△ NOTE
Pull in or pull out PC port and Acc port when main unit is turned off. Please
comply with the NOTE.
1.8 Connection of Power Cord and Grounding Wire
WARNING
Before plugging in the power cord, make sure the POWER switch is
turned off.
The procedures are as follows, shown in Figure 1-4.
1）Confirm power supply lines and ground connection are OK.
2）Confirm voltage of power supply is OK. (AC100-240V).
3）Plug the two sides of power cord into power supply output socket and
instrument power supply input socket respectively.
