CHAPTER 2 FUNCTION
23
2.5 Sample Compartment
UV2600 sample compartment can be seen in Figure 2-5.(Single cell holder is
standard configuration).
UV2600 can configure options such as single cell holder, micro cuvette holder,
glass test holder, film holder, rectangle long holder, flow cell assembly, 6-port
positioner with temp control, manual 5-cell holder and autosipper etc. Thease
options are installed inside sample compartment and can be replaced easily.
As for installation and use of options, refer to option instruction manual
Figure 2-5 UV2600 Sample Compartment（Single cell holder）
Measurement
cell
Reference
cell
