CHAPTER 4 MAINTENANCE
44
Figure 4-18 Replacement and adjustment of D2 Lamp
Figure 4-19 Relative position of D2 lamp facula and light-entrance slit
Confirm D2
lamp facula at
this position.
Viewfinder
Screw
B
Nut B
D2 lamp assembly
D2 lamp facula
Light-entrance
slit
Normal status
Horizontal deviation
Vertical deviation
