Technalogix TP1000 - MPEG2 to MPEG4 Transcoder (TC4) Setup

64
Introduction to the parameters of status:
Parameters
Description
Input Rate (TS#)
the input bitrate of channel1~channel12
Output Rate(TS#)
the output bitrate of channel1~channel12
ECM
the bitrate of ECM stream generated by ECMG
EMM
the bitrate of EMM stream generated by EMMG
ECMG
communication
Status
The communication status between ECMG and Scrambler. Green
means the status is good, while red indicates the communication is
interrupted.
EMMG
communication
Status
The communication status between EMMG and Scrambler. Green
means the status is good, while red indicates the communication is
interrupted.
ECM Count
The number is the number of ECM, also the number of programs you
have scrambled.
Count
The number is the accumulated number of EMM, which should keep
increasing to send the EMM to scrambler.
3.1.4.12 MPEG2 to MPEG4 (TC4) Transcoder Module
The MPEG2 to MPEG4 transcoder module supports transforming two MPEG-2 HD or four
MPEG-2 SD programs to MPEG4 format simultaneously.
 Setting
Pic-3.1-62
