3.2.2. SNMP Management Information Base (MIB)
The Technalogix.mib file allows access to the following data via the SNMP protocol:
Read Only
Pallet Supply Voltage
- voltage level (Vdc)
Temperature
- temperature in (°C)
Total Current
- current on high voltage bus (Adc)
PA1 Current
- current to pallet or device 1 (Adc)
PA2 Current
- current to pallet or device 2 (Adc)
Fan Current
- current to cooling fan(s) (Adc)
Reflected Level
- reflected level as % rated full scale
Forward Level
- forward level as % rated full scale
Deviation
- modulation level as %
Left Level
- left audio input level shown as dB
Right Level
- right audio input level shown as dB
Serial Number
Model Number
SNMP Error Flag
- error flag, also for trap (see below)
VSWR Flag
- error flag for high VSWR
Overdrive
- error flag for overdrive
Temperature Flag
- error flag for high temperature
Pre-emphasis
- 0,25,50 or 75 us
Read/Write
Reset
- 1 Reset System
0 Normal
Carrier On
- 1 Carrier On
0 Carrier Off
Carrier Up
- 1 Increase Carrier Level for AGC target 1%
Carrier Down
- 1 Decrease Carrier Level for AGC target 1%
VSWR Trip point
- 1-8 for 1.1:1 – 1.8:1
Frequency
- 875 – 1080 for 87.5 to 108.0 MHz
AGC Setpoint
- set target output power 0-100% rated power
Analog/Digital
- 1 Analog audio input
Digital Input
- 1 AES
2 SPDIF
3 TOSLINK
Analog Input
- 1 Mono
2 Stereo
3 MPX
Left Audio Level
- 0 – 255
0 = 0% 255 = 100%
Right Audio Level
- 0 – 255
0 = 0% 255 = 100%
MPX Level
- 0 – 255
0 = 0% 255 = 100%
SCA1 Level
- 0 – 255
0 = 0% 255 = 100%
SCA2 Level
- 0 – 255
0 = 0% 255 = 100%
Read and Write communities can be set from the web interface, as described earlier in
this section.
