5. Installation is the reverse of removal:
a. Connect the electrical connectors to the PSU.
b. Place the PSU into the housing and secure the PSU into place with the 2 holding screws.
c. Slide the grounding pass-through PSU leads’ clips into the housing slots, ensuring they are seated down to the
bottom of the slots.
a. Replace the PSU cover and secure it with 2 x crosshead screws.
b. Apply power and ensure that the PSU green LED is on, indicating that the PSU is functioning.
