Safety
Caution: AC voltages in the range of 20 – 90 VAC (110/230 VAC local power) can
be present when power is connected to the DBD-1200. Observe all notes and
cautions in this user guide.
Intended audience
The DBD-1200 User Guide is intended for network engineers and technicians responsible for planning, configuring,
installing and testing the Technetix DBD-1200 amplifier. Installers should have a working knowledge of coaxial cable
systems and cabling practices.
Specific tools list
The following tools and supplies are required when installing a DBD-1200:
■ 6mm hex key for the lid bolts
■ Set of crosshead screwdrivers
■ Pair of linesman’s pliers (only needed if changing the diplex) filters)
■ Torque wrench
■ Appropriate bolts/screws/washers for mounting the DBD-1200 (see page 7)
■ Appropriate USB for the:
☐ DBDCM-A-1 FSK module (for local control/ALSC)
☐ DBDCM-B-2 DOCSIS control module (DOCSIS cabling is included in transponder set)
☐ T-box (for bluetooth/Wi-Fi communication)
The connector on the other side of the cable will depend on the device you are using.
