Modules available for the DBD-1200

Upstream (US)

DBUS-A-1 Main module: 105MHz US ampliﬁer 25dB gain and IDS

DBUS-C-1 Main module: 204MHz US ampliﬁer 26dB gain and IDS

DBUS-D-1 Bridger module: 204MHz US ampliﬁer 26dB gain and IDS

Downstream (DS)

DBDS-B-4-1 Main: 1.2GHz DS ampliﬁer 44dB

DBDS-B-4-ET Main: 1.2GHz DS ampliﬁer 44dB - ET.25dB tilt

DBDS-B-5-1 Main: 1.2GHz DS ampliﬁer 38dB

DBDS-B-6-1 Main: 1.2GHz DS ampliﬁer 32dB

DBDS-B-7-1 Main: 1.2GHz DS ampliﬁer 44dB - 53dbmV output

DBDS-B-7-ET Main: 1.2GHz DS ampliﬁer 44dB - 53dbmV output ET.25dB tilt

DBDS-F-1 Bridger: 1.2GHz DS ampliﬁer 44dB

DBDS-F-2 Bridger: 1.2GHz DS ampliﬁer 44dB

DBDS-F-5-1 Bridger: 1.2GHz DS ampliﬁer 44dB - 53dbmV output

Control module

DBDCM-A-1 AGC/ALSC, FSK, USB-A (Mini USB)

DBDCM-B-2 AGC/ALSC, DOCSIS transponder compatible (USB-A)

DBDDM-A-1 DOCSIS 3.0 transponder (RS232 & MCX)

DBDDM-B-1 EuroDOCSIS 3.0 Transponder

Diplexer

DBDIP-xx A range of diplex ﬁlters where:

xx= 01: 65/85 MHz

xx= 02: 85/102 MHz

xx= 03: 204/258 MHz

xx= 04: 42/54 MHz

xx= 05: 85/105 MHz

Power

DBPSU-04 power supply available for line powering (nominal 65 VAC) 20-65V.

DBPSU-05 230 VAC Power supply for local powering.
