1404/2019 - EN/V9 Technetix Group Limited
Product user manual
DBE-1200S
3.4 Configuring the Power Supply Unit (PSU)
The DBE-1200S has the following power supply options:
1. Local powering is achieved on the RF input port using a power inserter.
2. Remote powering through the External Power port (see item 16 on page six). Maximum AC power passing = 10 Amps.
See page Chapter 4.1 for removal/installation of PSU unit.
Fuses
Referring to the network design documentation, remove any fuses not required for passing power.
Remove fuses on the output ports of the
DBE-1200S if it is not necessary to carry power.
Ext. power port
