1604/2019 - EN/V9 Technetix Group Limited
Product user manual
DBE-1200S
3.6 Downstream activation
Connect a spectrum analyzer to the input -20 dB test point, then measure and record the RF pilot frequencies’ input levels as
per the design drawings.
DBE-1200S input testpoint
Note: Ensure all amplifier ports are connected to a 75 Ω terminated load so that the RF test instrument readings are correct.
