3504/2019 - EN/V9 Technetix Group Limited
Product user manual
DBE-1200S
5.7 Optical modules
The platform has the following main modules for default node applications:
DBRX-A-1 1.2 GHz optical receiver module
DBTX-A-1 204 MHz dual optical transmitter module
DBLB-31-3D-1 Plug-in laser board 1310 nm 3 dBm analog
DBLB-55-3D-1 Plug-in laser board 1550 nm 3 dBm analog
DBLB-cxx-3D-1 Plug-in laser board CWDM wavelength selection 3 dBm analog
DBLB-CB-1 Combining board for hybrid RF/Node configuration which combines upstream over signal laser.
DBLB-BP-1 Terminating board (also called a bypass board) in case of a single upstream in a DBE for the secon slot
in DBTX-A-1
19011201 MCX to F-female adapter for measuring upstream RF level
Other output power and wavelength options are available, please contact your local sales representative for further information.
